Compact, Lightweight and Sleek design
Overload protection system if the torque exceeds the stirrer ratings
Safety circuits: Circuit auto cut-off feature for additional protection
Maintenance-free Brushless DC motor
The through-shaft housing design allows for easy impeller height adjustments and thereby less downtime in between sample changes
Availability: | |
---|---|
Features:
● Compact, Lightweight and Sleek design
● Speed Range: 50rpm~2000rpm
● Provides constant speed even with changes in viscosities of the sample
● Wide LED display for precise speed adjustment and monitoring
● LED display shows actual and set speeds alternately
● Overload protection system if the torque exceeds the stirrer ratings
● Safety circuits: Circuit auto cut-off feature for additional protection
● Maintenance-free Brushless DC motor
● The through-shaft housing design allows for easy impeller height adjustments and thereby less downtime in between sample changesad Stirrer,Digital Overhead Stirrer manufacturer
er,wholesale LED Overhead Stirrer
Features:
● Compact, Lightweight and Sleek design
● Speed Range: 50rpm~2000rpm
● Provides constant speed even with changes in viscosities of the sample
● Wide LED display for precise speed adjustment and monitoring
● LED display shows actual and set speeds alternately
● Overload protection system if the torque exceeds the stirrer ratings
● Safety circuits: Circuit auto cut-off feature for additional protection
● Maintenance-free Brushless DC motor
● The through-shaft housing design allows for easy impeller height adjustments and thereby less downtime in between sample changesad Stirrer,Digital Overhead Stirrer manufacturer
er,wholesale LED Overhead Stirrer
Model | OHS-40D |
Max. torque [N·cm] | 40 |
Speed range [rpm] | 50-2000 |
Speed increment [rpm] | Stepless, 10rpm |
Speed accuracy | ±1% |
Viscosity max. [mPas] | 50,000 |
Chuck diameter range [mm] | 0.5-10 |
Max. stirring quantity (H20)[L] | 40 |
Voltage [V] | 100-240 |
Frequency [Hz] | 50/60 |
Max. Output Power [W] | 110 |
Speed display | LED |
Overload protection | YES |
Motor protection | YES |
Over temperature protection | YES |
Dimensions (D×W×H)[mm] | 71×160×192 |
Weight [kg] | 2.8kg |
Protection class according to DIN EN60529 | IP42 |
Permissible ambient temperature [°C] | 5-40 |
Permissible relative humidity [%] | 80 |
Model | OHS-40D |
Max. torque [N·cm] | 40 |
Speed range [rpm] | 50-2000 |
Speed increment [rpm] | Stepless, 10rpm |
Speed accuracy | ±1% |
Viscosity max. [mPas] | 50,000 |
Chuck diameter range [mm] | 0.5-10 |
Max. stirring quantity (H20)[L] | 40 |
Voltage [V] | 100-240 |
Frequency [Hz] | 50/60 |
Max. Output Power [W] | 110 |
Speed display | LED |
Overload protection | YES |
Motor protection | YES |
Over temperature protection | YES |
Dimensions (D×W×H)[mm] | 71×160×192 |
Weight [kg] | 2.8kg |
Protection class according to DIN EN60529 | IP42 |
Permissible ambient temperature [°C] | 5-40 |
Permissible relative humidity [%] | 80 |
