Compact, Lightweight and Sleek design
Overload protection system if the torque exceeds the stirrer ratings
Safety circuits: Circuit auto cut-off feature for additional protection
Maintenance-free Brushless DC motor
The through-shaft housing design allows for easy impeller height adjustments and thereby less downtime in between sample changes
| Availability: | |
|---|---|
Features:
Compact, Lightweight and Sleek design
Speed Range: 50rpm~2000rpm
Provides constant speed even with changes in viscosities of the sample
Wide LED display for precise speed adjustment and monitoring
LED display shows actual and set speeds alternately
Overload protection system if the torque exceeds the stirrer ratings
Safety circuits: Circuit auto cut-off feature for additional protection
Maintenance-free Brushless DC motor
The through-shaft housing design allows for easy impeller height adjustments and thereby less downtime in between sample changes
Model | OHS-20D |
Max. torque [N·cm] | 20 |
Speed range [rpm] | 50-2000 |
| Speed increment [rpm] | Stepless, 10rpm |
| Speed accuracy | ±1% |
Viscosity max. [mPas] | 10,000 |
Chuck Diameter Range [mm] | 0.5-10 |
Max. stirring quantity (H20)[L] | 20 |
Voltage [V] | 100-120/200-240 |
Frequency [Hz] | 50/60 |
Max. Output Power [W] | 60 |
Speed display | LED |
Overload protection | YES |
Motor protection | YES |
| Over temperature protection | YES |
Dimensions (D×W×H)[mm] | 71×160×192 |
Weight [kg] | 2.8kg |
Protection class according to DIN EN60529 | IP42 |
Permissible ambient temperature [°C] | 5-40 |
Permissible relative humidity [%] | 80 |
