Features
Sample throughput: Comes with 48-well design and two models. 4-channel 48E can detect up to 4 target types per tube at the same time, while 2-channel 48R can detect up to 2 targets.
Efficient temperature control: It only takes 40 minutes to complete a standard PCR amplification program Temperature accuracy is controlled within 0.1℃.
Fast fluorescence scanning: Only 2 seconds, all 48-hole 4(48E)-/2(48R)-color fluorescence scanning can be completed.
Easy to Use: Designed with a built-in 7-inch full-color touch screen, independent control system and USB port for data export with the storage of at least 1000 experiments.
For the stand-alone operation the device can also be connected to a thermal printer (optional), the sample amplification curves, and CT values can be directly printed out.
Compatible with the fluorescence analysis functions of a variety of isothermal amplification technologies.
A set of independent data management software is also built in 48E/48R for the centralized management and analysis of your massive experimental data, to minimize the errors caused by manual analysis of original data.
Real-Time PCR ,Gradient PCR,Real-Time qPCR System,gradient pcr machine
Features
Sample throughput: Comes with 48-well design and two models. 4-channel 48E can detect up to 4 target types per tube at the same time, while 2-channel 48R can detect up to 2 targets.
Efficient temperature control: It only takes 40 minutes to complete a standard PCR amplification program Temperature accuracy is controlled within 0.1℃.
Fast fluorescence scanning: Only 2 seconds, all 48-hole 4(48E)-/2(48R)-color fluorescence scanning can be completed.
Easy to Use: Designed with a built-in 7-inch full-color touch screen, independent control system and USB port for data export with the storage of at least 1000 experiments.
For the stand-alone operation the device can also be connected to a thermal printer (optional), the sample amplification curves, and CT values can be directly printed out.
Compatible with the fluorescence analysis functions of a variety of isothermal amplification technologies.
A set of independent data management software is also built in 48E/48R for the centralized management and analysis of your massive experimental data, to minimize the errors caused by manual analysis of original data.
Real-Time PCR ,Gradient PCR,Real-Time qPCR System,gradient pcr machine
Model | 48E | 48R |
Throughput | 48 | 48 |
Fluorescence Channels | 4 | 2 |
Compatible Fluorophores | Channel 1: FAM, SYBR Green I, etc. Channel 2: VIC, HEX, TET, JOE, etc. Channel 3: ROX, Texas Red, etc. Channel 4: Cy5, etc. | Channel 1: FAM, SYBR Green I, etc. Channel 2: VIC, HEX, TET, JOE, etc. |
Light Source | High-brightness, long-life and maintenance-free LED light source | |
Detector | Photodiodes (PDs) | |
Fluorescence Scanning Time | 48-well 4-channel detection completed within 2s | 48-well 2-channel detection completed within 2s |
Heating Rate | Maximum heating ramp rate ≥8.0℃/s; Average heating ramp rate ≤6.2℃/s | |
Cooling Rate | Maximum cooling ramp rate ≥6.2℃/s; Average heating ramp rate≥4.5℃/s | |
Temperature Accuracy | ≤ 0.1℃ | |
Special Temperature Setting Function | Support thermal gradients PCR, long PCR, Touch Down PCR | |
Suitable Consumables | 0.2ml clear non-skirt 48-well plates, 8-tube strips, single tubes, etc. | |
Sample Testing linearity and Repeatability | linear Correlation: CV≥0.999 Repeatability: cycle threshold (Ct) value CV ≤0.5% | |
Software Analysis | Qualitative analysis, absolute quantitative analysis, relative quantitative analysis, end point fluorescence analysis, melting curve analysis, and genotyping analysis, etc. | |
Control Method | Stand-alone operation: 7-inch touchscreen control; Cloud-enabled: PC software control via direct connection or LAN (local area network); Up to 10 devices controlled by one PC | |
Power Failure Protection | Automatic recovery of the experiment and other functions when the power is on again after cutting off, without waiting for the power-on of the computer or software control | |
Data Storage and Transmission | A single machine can store more than 1,000 experimental data files, which can be imported and exported via USB disks | |
Stand-Alone Analysis Results | No need for an extra computer: experimental data analysis enabled within the instrument; Direct printing function (optional) to output the sample amplification curve and CT value, simply by connecting to the compatible thermal printer | |
Reporting Function | Built-in experiment report templates for a variety of industries; Fully open universal reporting of which the contents and formats can be customized | |
Operating System | Windows XP Pro or higher | |
Power Supply and Power Consumption | AC 100-240V, 50-60Hz; 600VA | |
Weight | 11Kg (net) | |
Instrument Dimension | 260x400x260mm |
