Real-Time Fluorescent Quantitative PCR System 960406 (96 wells)

960406 Real-time PCR is a 96 well quantitative fluorescence Real-time PCR System, equipped with a 10.1-inch high-definition color touch screen and built-in analysis software for intuitive operation and analysis. Combining the innovative thermal cycling system, accurate photoelectric detection system and intuitive software, the real-time PCR delivers precise and reproducible experimental results. The device also has two temperature control modes settings which enables you to control either block or tube temperatures.
Availability:

Features

  • Advanced optical system including full-spectrum high-power LED and high-sensitive PMT top scanning achieves higher sensitivity you need in researches and experiments.

  • High-precision temperature control over the block with a resolution of 0.1 ℃ offers reliable and consistent qPCR assay data.

  • Gradient temperature range is 30-100℃ and the temperature difference between adjacent blocks can be high up to 40℃ for assay optimization.

  • Sample tray automatically moves in/out, enabling integration with automated workstations/plate handlers for unmanned detection.

  • 6 fluorescence channels without cross talk and 96-well high-throughput process at a single run meet a variety of qPCR assay demands.

  • The 10.1-inch large touch screen facilitates flexible programming and efficient running of PCR protocols.

  • The intuitive built-in software and PC software for improved user's experience allow you to run and analyze qPCR data from personal computer

  • Two temperature control modes enable you to control either block or tube temperatures.


Multiple Applications

The Real-Time Fluorescent Quantitative PCR System uses fluorescence real-time detection method to analyze the amplification of PCR template. It is suitable for human genome engineering, forensic medicine, oncology, population biology, paleontology, zoology, botany and other research fields.



This PCR detection system can be an in vitro diagnostic medical device, which is suitable for polymerase chain reaction fluorescence quantitative detection in the field of clinical diagnosis of viruses, tumors, genetic diseases, etc.


pc software

Model

96046

Throughput

96 well (12X8)

Applicable consumables

PCR single tube or strip, 96well*0.2ml half skirted/ no skirted plate

Dynamic range

1-1010copies

Detection location

Top detection

Excitation light wavelength

400-800nm

Detection wavelength

500-800nm

Fluorescence channels

6 channels

Fluorochrome / dye

Channel 1: FAM/SYBR Green I      Channel 2: JOE/HEX/TETA/IC

Channel 3: NED/TAMRA/Cy3       Channel 4: ROX/Texas Red

Channel 5: Cy5                             Channel 6: Cy5.5

Excitation light source

full-spectrum LED

Detector

PMT

Block temperature range

4-105°C

Block temperature accuracy

≤±0.1℃

Block temperature precision

≤±0.1℃

Block temperature uniformity

≤±0.1℃

Max. heating & cooling rate of block

≥6℃/S

Gradient temperature difference

1-40°C

Block temperature control mode

Block mode, Tube mode

Sample volume range

5-100 µL

Heated lid temperature range

30°C-110°C (default 105°C)

Fluorescence intensity

CV ≤3%

Detection repeatability

Yes

Touch screen

10.1-inch touch screen

Scan mode

Full plate scan or specified line scan

Software functions

Absolute quantification, Relative quantification,

Melting curve, SNP genotyping, HRM, Quick run, etc.

Operation system

PC software (Windows 8 or higher), Built-in software

Ports

USB Type-A port x 2, USB Type-B port, RJ45 port

Power-off protection function

YES. Data can be restored after power-on

Sample tray control mode

Sample tray automatically moves in/out, enabling integration with automated workstations/plate handlers.

Dimensions

320(W)mmx525(L)mmx420(H)mm

Net weight

27 kg
