Features:
●Compact design: can be used in incubators and cold rooms
●Adjustable speed of 0–100rpm
●Max.loading capacity (with platform) is 2kg
●Undulating three-dimensional shaking motion, with 0°-8° adjustable tilt angle
●No-slip mat on the platform keeps the items in position during operation
●Ideal for generating the three-dimensional motion commonly preferred for molecular biology applications
3D Rocker,Digital 3D Rocker,3D Rocker manufacturer
Features:
●Compact design: can be used in incubators and cold rooms
●Adjustable speed of 0–100rpm
●Max.loading capacity (with platform) is 2kg
●Undulating three-dimensional shaking motion, with 0°-8° adjustable tilt angle
●No-slip mat on the platform keeps the items in position during operation
●Ideal for generating the three-dimensional motion commonly preferred for molecular biology applications
3D Rocker,Digital 3D Rocker,3D Rocker manufacturer
Model | SK410 |
Shaking motion | Three - dimensional shaking |
Tilt angle [°] | 0-8° |
Max. load capacity (with platform) [kg] | 2 |
Motor type | Brushless DC motor |
Speed range [rpm] | 0-100 |
Operation type | Continuous operation |
Voltage [VAC] | 100-240 |
Frequency [Hz] | 50/60 |
Power[W] | 5 |
Permissible ambient temperature [℃] | 5-40 |
Permissible relative humidity [RH] | 97% |
Protection class acc. to DIN EN60529 | IP42 |
Dimension (L x W x H) [mm] | 190x90x160 |
Weight [kg] | 1.9 |
